Polyester Modified Enameled Copper Clad Aluminum Wire Round Wire
| Place of Origin | Zhejiang, China |
|---|---|
| Brand Name | CHINGCUNG |
| Certification | UL/ISO9001/ISO14001/RoHS/Reach |
| Model Number | PECCAW-GB/155-0.07 |
| Minimum Order Quantity | 30 Kg |
| Price | USD 244.44/Kg |
| Packaging Details | 5 Kgs each roll, cartons. |
| Delivery Time | 5-7 work days |
| Payment Terms | T/T |
| Supply Ability | 50 tons per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Order No. | 30021452070 | Product Name | Class 155 Copper Clad Aluminum Wires |
|---|---|---|---|
| Conductor | CCA | Stock | Yes |
| Conductor Thickness | 0.07mm | Applicationdownloads | Transformer,generator,relays |
| High Light | Polyester Enameled Copper Clad Aluminum Wire,CCA Copper Round Wire,0.07mm Enameled Copper Clad Aluminum Wire |
||
Product Description
Self Bonding Polyester Modified Enameled Copper Clad Aluminum Wire Round Wire Customized
FEATURES:
Enamelled copper clad aluminum wire is a new electromagnetic wire taking copper clad aluminum as inner conductor material, with characteristics between copper and aluminum. It combines excellent conductivity of copper and light weight of aluminum.
We supply various types of special self-bonding enameled wiresmainly, including copper-clad aluminum self-bonding wires,alloyself-bonding wires, self-bonding stranded wires, silver-platedwires,240 grade high temperature self-bonding wires,etc. Weproduce all kinds of alloy self-bonding wires of 0.02mm-0.10mm,as well as copper-clad aluminum ultra-high tension self-bonding wires and copper self-bonding wires of 0.04mm-0.90mm.
At the same time,we can also customize various.types ofself-bonding enameled wires to meet different national standardsfor customers, according to the technical parameters provided by customers.
Our factory is equipped with automatic manufacturing facilitiesand advanced testing and inspection equipments. We have anumber of patent certificates,strong technical strength.At thesame time, we also have perfect production management system and quality assurance system to maintain the stability and reliability of our products.
Specification:
| Model Number | PECCAW-1B/155 | PECCAW-2B/155 | PECCAW-GB/155 | PECCAWY3-1B/155 | PECCAWY3-2B/155 | PECCAWY3-GB/155 |
| Conductor Material | CCA | CCA | CCA | CCA | CCA | CCA |
| Conductor Diameter(mm) | 0.04-0.90 | 0.04-0.90 | 0.04-0.90 | 0.04-0.90 | 0.04-0.90 | 0.04-0.90 |
| Bonding Method | Alcohol Soluble | Alcohol Soluble | Alcohol Soluble | Hot Air | Hot Air | Hot Air |
| Thermal Class | 155 | 155 | 155 | 155 | 155 | 155 |
| Shape | Round | Round | Round | Round | Round | Round |
FAQ:
Q1:What's self-bonding enamelled copper wire?
A:Self-bonding enamelled copper wire is a special type of enamelled wire with an additional adhesive enamel overcoat such as thermoplastic resin. This adhesive has a bonding feature, which is activated by heat or solvents. Once activated the adhesive bonds turn to turn windings into a compact self supporting coil. The use of self bonding wire may offer cost and manufacturing advantages in some winding applications as bobbins, tape, varnishing, or impregnation may be eliminated.
Q2:Do you have your own R&D team?
A:Yes, we can customize products as your requirements.
Q3:What's the main market of your company?
A:We have customers all over the world.
Q4:What is your terms of payment ?
A:Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance, balance before shippment.
Q5:Can you provide samples? Charge or free?
A:Yes, we can provide samples for payment, which can be sent to you by DHL express or FOB.
